TAG Series 9 Hydraulic Quick Coupler | Width 48″-84″ | Machine Size 9-30 Tons | For Wheel Loaders

Description

Product Description

TAG Series 9 Hydraulic Quick Coupler | Width 48″-84″ | Machine Size 9-30 Tons | For Wheel Loaders

The TAG Series 9 Hydraulic Quick Coupler is designed for wheel loaders operating in fleet environments that use CAT vertical twin-cylinder attachments. With a robust frame and seamless interface geometry, this coupler allows fast interchange and high-load performance while preserving compatibility with CAT-style buckets, forks, and grapples.

TAG engineered the Series 9 with a reinforced heavy-duty carriage and a vertical twin-cylinder actuation system, offering secure locking and tight tolerance handling. Each coupler comes with a complete hydraulic kit, reducing install time and ensuring plug-and-play operation across compatible machines. This system is not compatible with CAT-style IT couplers featuring horizontal cylinders.

Key Features

• CAT Compatibility: Interchanges with CAT-style vertical twin-cylinder attachments.
• Cylinder Layout: Twin vertical hydraulic cylinders for synchronized locking.
• Coupler Construction: Heavy-duty reinforced carriage resists flex and stress, Precision coupler geometry ensures tight fit and secure hold.
• Hydraulic Integration: Includes full hydraulic kit for fast setup.
• Application Scope: Ideal for fleet operations using CAT buckets and forks.
• Mounting Restriction: Not compatible with CAT IT couplers (horizontal cylinder configuration).

Detailed Specifications

Model: H9QC200
